Description
C2122 is a double pitch conveyor roller chain with large rollers and straight side plates, with a pitch of 76.2 mm (3 in). Double pitch chain halves the number of links needed for a given conveyor length while keeping the same strength class, which makes it the standard choice for very heavy duty conveying. The chain is supplied cut to the exact length of your conveyor.
Available Models
C2122 specification:
| Model | C2122 |
| Pitch | 76.2 mm (3 in) |
| Chain type | Double pitch conveyor roller chain |
| Roller | Large roller |
| Side plates | Straight side plates |
| Duty class | Very heavy duty |
| Material | Carbon steel, with stainless steel available on request |
| Length | Standard coils, or cut to your required length |
| Sprockets | Matching double pitch sprockets available on request |
| Attachments | Available on request |
| Customization | OEM and ODM available, customer brand accepted |
| MOQ | Please contact our sales team to confirm |
| Packing | Standard export packing, customized packing on request |
| Place of origin | Xiamen, China |
Product Features
- Double pitch construction: the pitch is twice that of a standard roller chain, so half the number of links covers the same centre distance
- Pitch 76.2 mm (3 in), selected for very heavy duty conveying duty
- Large rollers on every link, running on the sprocket teeth for smooth travel and low friction
- Straight side plates on both sides of the chain
- Standard plate and pin section, matched to the duty class of the chain
- Carbon steel with a protective finish, and stainless steel available on request
- Cut to the exact length of your conveyor, with matching double pitch sprockets available in the same order
Product Advantages
- Half the number of links compared with a standard pitch chain, which lowers chain cost and chain weight for the same conveying length
- Large rollers tolerate rail wear and small misalignments better, so the line keeps running without constant adjustment
- Very heavy duty rating for continuous operation in a wide range of conveying duties
- Straight side plates let the chain be supplied with attachments where the line also has to carry the load
- Cut to length and supplied with matching sprockets, so the whole conveyor drive arrives in one order
- A damaged section can be replaced link by link, which keeps a conveyor line running
- More than ten years of production and export experience, with technical support from our engineers
Applications
C2122 is used in the following applications. Typical uses include:
- Heavy bulk conveying
- Mining, cement and aggregate plants
- Heavy timber handling
- Large pallet systems
- Primary material handling
